Electrolyzer
parameter
|
Rated hydrogen production | 1000±5% Nm³/h（continuous, stable and adjustable） |
| Rated oxygen production | 500±5% Nm³/h（continuous, stable and adjustable） | |
|
Rated capacity electricity consumption
|
≤4.6kWh/Nm³H2（electrolytic cell energy consumption） | |
| System operation pressure | 1.6MPa±5%（In 30%~110% load range) | |
|
Load regulation range
|
30~110% | |
| hydrogen purity | ≥99.7%(Electrolyzer Outlet,Before hydrogen purification) | |
| Oxygenpurity |
≥98.5%(Electrolyzer Outlet)
|
|
| System efficiency | ≥90%（After heat recovery） | |
|
Lifetime
|
80000h~100000h（Subject to conditions of use） | |
|
Purification
system
parameter
|
Purification system capacity |
1000±5% Nm³/h（continuous, stable and adjustable）
|
|
Hydrogen purity
|
≥99.9997%（After purification) | |
| Hydrogen pressure at Purification outlet | 1.5MPa±5%（In 30%~110% load range) | |
| Oxygen content | ≤5 ppm | |
|
Dew point
|
Dew point≤-65℃ | |
|
Operating
Conditions
|
Operation Temperature
|
-30℃ to 45℃（Container temperature） |
| Operation Humidity | 5~95%RH | |
|
Altitude
|
≤ 2000m | |
| Main supply voltage | 10kV, 50Hz, three phase | |
| Auxiliary supply voltage | 380V, 50Hz, three phase |
